iLR-Victoria-ref-[1.62-3.63]-[0.8-2.5].02, as any Power Management Virtual Component designed by Dolphin Design, is readily re-targetable toward any sub micron CMOS process.

Key Benefits

  • Low dropout: 380mV of dropout at ILOAD= IMAX
  • Low Bill-of-Material: optimized in density for the best trade-off for the given output current and input voltage range
  • A cost-efficient solution compared to external Power Management
  • Behavioral models: ease of integration in SoC and optimization of Power Management Network (PMNet) using models to verify mode transitions as well as noise propagation
  • Safe integration in the SoC thanks to transfer functions, templates and profiles included in the specification

Key Features

PARAMETERS CONDITION
Minimum value
Typical value
Maximum value
Input Voltage
- 1.62 V 3.63 V
Output Voltage
- 0.8 V 2.5 V
Output current configuration
- - 100 mA - 200 mA - 500 mA -

Applications

  • Smart Headset
  • TWS Earpods
  • Smart Speaker
  • Home Appliance
  • AR - VR
  • Voice Assistant
  • Infotainment
  • Hearing aids
  • Voice-controlled devices
  • Bluetooth
  • NB-IoT
  • ULP MCU
  • WiFi
  • GNSS
  • Cellular IoT

Key Performances

  • 3 % overall output voltage DC accuracy.
  • -45 dB typical PSRR @ DC.
  • 45 uA typical current consumption at no load.
  • 250 uVRMS total integrated noise from 20 Hz to 20 kHz

Technical information

  • Technology: TSMC 55 uLP eFlash
  • Add-ons:
    • Power-On-Reset and Brown-On-Reset circuit (POR-BOR) Temperature sensor Power ON indicator
