The ddAHB2TDM is an interface bridge between AHB and TDM or I2S, using parametrized RTL to set-up maximum number of TDM slots and operating mode. It provides up to 64 slots, 16 or 32-bits.
Key Benefits
- TDM
- Up to 64 slots, 16-bits or 32-bits size
- Independent number of slots
- Independent setting for input and output
- Independent activation/deactivation with possible sync continuity in FIFO
- Up to 768 kHz sampling frequency
- Left justified, 16, 20, 24, 32 bits capture
- APB control interface
- Duplex/Simplex support
Key Performances
- Up to 64 slots, 16-bits or 32-bits size
- Up to 768 kHz sampling frequency
- 16, 20, 24, 32 bits
