Ultra-low power and high accuracy crystal oscillator to generate a 32 kHz clock in the Always-on domain with minimum power consumption. Perfect fit for IoT applications with stringent power consumption in sleep and deep sleep modes.
Key Benefits
- Low power consumption: support of low power and backup modes
- High accuracy: can operate in various environment thanks to its outstanding stability over a large range of temperature
- A cost-efficient solution: no external component is needed (except a quartz) thanks to on-chip integrated capacitors.
- A flexible solution: users have the possibility to add capacitors depending on the external crystal selected for a better frequency fitting
- By-Pass Mode: the oscillator could be by-passed during tests
Key Features
| PARAMETERS | CONDITION |
Minimum value
|
Typical value
|
Maximum value
|
|---|---|---|---|---|
|
Input Voltage
|
- | 0.81 V | 1.21 V |
Applications
- Bluetooth
- Cellular IoT
- GNSS
- Hearing aids
- NB-IoT
- Smart Headset
- Smart Speaker
- TWS Earpods
- ULP MCU
- Voice-controlled devices
- Voice Assistant
- WiFi
Key Performances
- 80 nA power consumption @ 0.9V
- 50 ppm frequency accuracy
Technical information
- Technology: TSMC 40 LP
- Add-ons:
- *
