eSR-Niagara-Bu-dm-ref-[1.62-3.63]-[0.8-2.5].01, as any Power Management Virtual Component designed by Dolphin Design, is readily re-targetable toward any sub micron CMOS process.

Key Benefits

  • High efficiency buck regulator (up to 90%)
  • PFM based mode allowing high-efficiency at low load
  • Configured output drive before delivery to fit the application
  • Low Bill-of-Material: fully integrated feedback and active compensation loop do not require additional external passive components
  • Low Output Ripple
  • Protected Output: over current protection
  • Over temperature protection
  • Soft-start

Key Features

PARAMETERS CONDITION
Minimum value
Typical value
Maximum value
Input Voltage
- 1.62 V 3.63 V
Output Voltage
- 0.8 V 2.5 V
Output current configuration
- - 100 mA - 200 mA -

Applications

  • Smart Headset
  • TWS Earpods
  • Smart Speaker
  • Home Appliance
  • AR - VR
  • Voice Assistant
  • Infotainment
  • Hearing aids
  • Voice-controlled devices
  • Bluetooth
  • NB-IoT
  • ULP MCU
  • WiFi
  • GNSS
  • Cellular IoT

Key Performances

  • Up to 95% peak efficiency (for NDO configurations).
  • 90 % efficiency down to 0.2 IMAX (for NDO configurations).
  • 70 % efficiency down to 0.01 IMAX (for NDO configurations).
  • 3 % DC output voltage accuracy

Technical information

  • Technology: TSMC 55 uLP
  • Add-ons:
    • Over-voltage protection module (OPM) required for 2.7 to 5.5 V and 1.9 to 4.4 V input voltage range. The OPM enables over-voltage operation (up to 5.5 V) while using standard process 3.3 V devices. Power-On-Reset and Brown-On-Reset circuit (POR-BOR) Temperature sensor Power ON indicator
