Combined Power On Reset and Brown Out Reset.
Applicable to automotive, industrial. Designed for extended mission profile (aging report available)
Key Benefits
- Ultra low power consumption in normal mode and in low power mode enabling to optimize the overall consumption of the Always-On-Domain
- Possibility to disable the BOR monitoring during low power mode in order to save power
- High programmability: POR and BOR thresholds are all programmable. BOR allows a dynamic programming to comply with the supply voltage of the power domain
Key Features
| PARAMETERS | CONDITION |
Minimum value
|
Typical value
|
Maximum value
|
|---|---|---|---|---|
|
Input Voltage
|
- | 1.62 V | 3.63 V | |
|
Output Voltage
|
- | 0.55 V | 3.3 V | |
|
Output current configuration
|
- | - | NONE | - |
Applications
- Automotive
- Bluetooth
- Cellular IoT
- GNSS
- Hearing aids
- NB-IoT
- Smart Headset
- Smart Speaker
- TWS Earpods
- ULP MCU
- Voice-controlled devices
- Voice Assistant
- WiFi
Key Performances
- Current consumption: 13 uA in normal mode and 5 nA in low power mode
- Typical BOR threshold voltage: 86% * Input monitored voltage
- Typical POR threshold voltage: 87% * Input monitored voltage
- ±3% accuracy (no trimming required)
Technical information
- Technology: TSMC 40 uLP eFlash
