Power-On-Reset and Brown-Out-Reset with programmable detection thesholds
Key Benefits
- A flexible offering enabling to implement only the relevant features
- Ultra low power consumption of 13 μ
- A in normal mode and 5 nA in low power mode enabling to optimize the overall consumption of the Always-On
- Possibility to disable the BOR monitoring during low power mode in order to save power
- High programmability: POR, PON and BOR thresholds are all programmable. BOR allows a dynamic programming to comply with the supply voltage of the power domain
- Re-bootable PON when the supply is re-started or reset
Key Features
PARAMETERS | CONDITION |
Minimum value
|
Typical value
|
Maximum value
|
---|---|---|---|---|
Input Voltage
|
- | 1.44 V | 1.98 V | |
Output Voltage
|
- | 0.6 V | 1.8 V |
Applications
- AR - VR
- Bluetooth
- Cellular IoT
- GNSS
- Hearing aids
- Home Appliance
- Infotainment
- NB-IoT
- Smart Headset
- Smart Speaker
- TWS Earpods
- ULP MCU
- Voice-controlled devices
- Voice Assistant
- WiFi
Key Performances
- Current consumption: 15 uA in normal mode and 100 nA in low power mode
- Typical BOR threshold voltage: 86% * Input monitored voltage
- Typical POR threshold voltage: 87% * Input monitored voltage
Technical information
- Technology: TSMC 22 uLL1.8
- Add-ons:
- -
